Model VIS-ML600LED:

• Voltage Input: 12 VDC / 24 VDC
• Current Draw: 12V / 500mA ; 24V / 250mA (±5%)
• Holding Force: Up to 600 lbs (272 kg)
• Hall Effect Contact: SPDT rated 2A at 24 VDC
• Magnetic Contact Rating: 28 VDC, 0.5A, 10W
• Anti-Rust Surface Treatment: Blue Zinc Plating
• Operating Temperature: 0~55° C (32~131° F)
• Weight (Magnet): 1.1 kg (±1%)
• Dimensions: Magnet - (L)250x(W)42x(T)25 mm Armature - (L)180x(W)38x(T)11 mm
• Green/Red LED Indication for EM Lock Status

Model No. VIS-3031:

• Standalone Application: The unit needs to be connected to the ethernet so you can use the software and add fingerprints.
• Communication: TCP/IP
• Working Voltage: DC12V±10%/1A
• Users / Records: 3.000 / 70.000
• Recognition Mode: RFID Fingerprint
• Wiegand Input: 1
• Wiegand: 26 - 34
• Exit Button Input: 1
• Door-magnet Input: 1
• Alarm Output / Input: 1 / 1
• Lock Control Output: 1
• Refusal Rate: < 0.01%
• Fales Rate: < 0.0001%
• Working Humidity: 20% ~ 60%
• Working Temperature: -10°C ~ 45°C (14°F ~ 113°F)
• Size: 122Lx77Wx45H (mm) - 4.80Lx3.03Wx1.77H (in.)

Model No. VIS-8004:

• Operating Frequency: 315mhz
• Number of Codes: 1,048,576
• Data Format: PWM
• Operating Voltage: +12V 24V
• Operating Distance: Up to 160ft (50m) - The maximum range needs to be used in an open area. The distance will start to diminish based on some type of interference such as metal, concrete and others.
• Operating Temperature: 0-70°C or 32 - 158°F
• Current Draw: 19mA
• Compatible Transmitter: VIS-8005
• RF channels: One
• No. of Remotes that are able to connect to one Receiver: Up to 50
• Receiver Output: C dry contact (NO/NC/COM)
• Receiver Output Functions: 4 (Default) 4 second momentary, latch, toggle (On/Off), press on function
• Connectors: 5 screw Terminal (NO, COM, NC + -)
• Case Construction: ABS Plastic
• Dimensions: 62*43.5*30mm (2.44* 1.71*1.18 Inches)
• Weight: 43g or 1.52 Ounces
• Certifications: FCC
• Antenna: Wire lead
• Mounting Screws: Comes with two mounting screws
• Warranty: 1 Year
• Wire Harness: Included
• Power supply: Not included (only included in the form of kits.)

Model No. VIS-8005:

• Frequency: 315mhz
• Chip: 1527
• Input Voltage: 6V
• Button Quantity: 1 button
• Input Power: 0.06W
• Input Current: 0.01A
• Up to 160ft (50m) - The maximum range needs to be used in an open area. The distance will start to diminish based on some type of interference such as metal, concrete and others.

Model No. VIS-7013:

• Contact Rating: 12-24V, 3A
• Output Contact: NO/NC/COM
• Detection Range: 5-15cm (1.96 - 5.90in.), Adjustable
• Power: 12VDC or 24VDC
• LED Color: Blue (Stand by Mode), Green (Active/Open Mode)
• Time Delay: 0.5~22s
• Panel: 4mm (0.15) Thick Aluminium Alloy (CNC)
• Suitable for: Hollow Door
• Mechanical Life: 100.000 tests
• Operating Temperature: -20°C~+55°C (14°F-131°F)
• Operating Humidity: 0-95% (relative humidity)
• Weight: 0.105kg
• Dimensions: 115L × 70W × 25H mm - 4.52L x 2.75W x 0.98H in.

Model No. IrexPlus:

• Voltage: 12-30 Volts DC or AC
• Current Consumption: 8 mA standby, 25 mA (Relay+LED), 44 mA maximum (Buzzer+Relay+LED) at 12/24 VDC
• Relay Output: 1A @ 30 VDC or VAC, two form “C” contacts
• Tamper Output: 50 mA @ 30 volts DC or AC
• Detection System
• Mounting Height: 2.3m - 4.6m (7.5' - 15')
• Detection Range: Up to 2.4m (8')
• Dimensions (LxHxD): 177mm x 50mm x 45mm (7'' x 2'' x 1.8'')
• Weight: 0.15Kg (0.3lb)
• Colour: White or Black
• Environmental
• RFI Immunity: 30 V/m from 10MHz to 2GHz
• Operating & Storage Temperature: -20°C to 60°C (-4°F to 140°F)

Model No. VIS-CP200:

• Input Voltage Range: AC90V-264V
• Input Frequency Range: 50Hz-60Hz
• Output Voltage Range: DC12V+/-5%
• Output Current: 2A
• Output Power: 24 Watts
• Output Ripple&Noise: ≤46MV
• Output Efficiency: ≥79%
• Environment Operating: -30°C~45°C 20%~90%RH
• Environment Storage Temp.: -40°C~85°C 10%~95%RH
• Product Dimension: 87*36.5*70mm (3.42x1.43x2.75in.)
• Product Weight: 116g
• Certificate: UL, CE, RoHS, FCC
