Do these locks work with both 12V and 24V power supplies?

Yes, each lock is compatible with 12V and 24V DC inputs, making it adaptable to different setups.

Will I be able to tell if the magnetic lock is working by looking at it?

Yes, the maglock has a bright-colored status LED. It provides a clear indication of the lock status, so you know at a glance if the door is secured.Green = LockedRed = ReleasedOff = No input

Can these magnetic locks be installed on glass/sliding doors?

Yes, they can be installed on glass doors and they can be installed on sliding doors. You might need a proper bracket.

300lb Indoor Electromagnetic Lock with LED Sensor VIS-ML300LED

Indoor Magnetic Door Lock. Up to 300 lbs (136 kg) Holding Force. Visionis (Unboxing)

Single Door Maglock VIS-ML300LED Visionis

Magnetic Lock 300 lbs Features VIS-ML300LED Visionis

Magnetic Lock 300 lbs Reviews VIS-ML300LED Visionis

indoor magnetic lock with LED status indicators, for access control systems VIS-ML300LED

300lb magnetic door lock with LED Sensor VIS-ML300LED

Description

IMPORTANT: This product doesn’t include a power supply. You can add this one to your purchase.

NOTE: This is a Fail Safe or Normally Close lock, meaning it will unlock without power. You can add a battery backup to keep the lock engaged in case of an outage.

Main Features

Holding Force

Up to 300 lbs (136 kg)

Voltage Input

12 VDC / 24 VDC

Applications

Indoor Only

Single Door Magnetic Lock

Maglocks are typically installed on the top corner of the door frame, with the magnet mounted on the frame and the armature plate attached to the door. This setup ensures a secure hold when the door is closed.

Color Magnetic Locks: Silver, Black, White

Multiple Color Options to Match Your Design

Our maglocks are available in silver, black, and white, allowing you to choose the perfect color to complement your door and overall decor.

LED Indicators

Built-in LED indicators provide real-time lock status, adding an extra layer of control and convenience.

RED = Maglock Released

GREEN = Maglock Locked

Installation Walkthrough

Characteristics

Model VIS-ML300LED:

Input Voltage: DC 12V / 24V
Current: 12V 300 mA (±5%); 24V 150 mA (±5%)
Function: Fail Safe (It locks with power)
Holding Force: Up to 300 lbs (136 kg)
Product Dimensions: Magnet - 210L x 35W x 21T mm
Armature - 130L x 33W x 11T mm
Weight: Magnet: 0.6 kg (±1%)
Anti-Rust Surface Treatment: Blue Zinc Plating
LED Color: Green = Locked / Off = Open / Red = Unlocked
Operating Temperature: 0 °C ~ 55 °C (32 °F ~ 131 °F)
Operating Humidity: 0 ~ 95% (non condensing)
Usage Environment: Indoor Only

Description

IMPORTANT: This product doesn’t include a power supply. You can add this one to your purchase.

NOTE: This is a Fail Safe or Normally Close lock, meaning it will unlock without power. You can add a battery backup to keep the lock engaged in case of an outage.

Characteristics

Model VIS-ML300LED:

Input Voltage: DC 12V / 24V
Current: 12V 300 mA (±5%); 24V 150 mA (±5%)
Function: Fail Safe (It locks with power)
Holding Force: Up to 300 lbs (136 kg)
Product Dimensions: Magnet - 210L x 35W x 21T mm
Armature - 130L x 33W x 11T mm
Weight: Magnet: 0.6 kg (±1%)
Anti-Rust Surface Treatment: Blue Zinc Plating
LED Color: Green = Locked / Off = Open / Red = Unlocked
Operating Temperature: 0 °C ~ 55 °C (32 °F ~ 131 °F)
Operating Humidity: 0 ~ 95% (non condensing)
Usage Environment: Indoor Only

Product FAQs

Do these locks work with both 12V and 24V power supplies?

Yes, each lock is compatible with 12V and 24V DC inputs, making it adaptable to different setups.
Will I be able to tell if the magnetic lock is working by looking at it?

Yes, the maglock has a bright-colored status LED. It provides a clear indication of the lock status, so you know at a glance if the door is secured.

Green = Locked
Red = Released
Off = No input
Can these magnetic locks be installed on glass/sliding doors?

Yes, they can be installed on glass doors and they can be installed on sliding doors. You might need a proper bracket.
What happens to the maglock when the power goes out?

This is a Fail Safe or Normally Close lock, meaning it will unlock without power. You can add a battery backup to keep the lock engaged in case of an outage.
Does the magnetic lock make a noise when unlocking?

The maglock makes a sort of clicking noise when it unlocks. If you want a louder noise to identify when the door unlocks, you can add a buzzer to your system.
Does it have a time delay or timer function?

No, it doesn't.
Is this magnetic door lock kit weatherproof?

This model is designed for indoor use only. For outdoor use, look for weatherproof-rated maglocks.

Download Datasheets and Manuals of this product

VIS-ML300LED

Visionis by Visionis

5.0

Indoor Magnetic Door Lock. 300 lbs (136 kg) of Holding Force. 12 VDC / 24 VDC - VIS-ML300LED Visionis

UPC Code: 701980451669

Certifications:

⚡ Order before 2:00 PM EST on weekdays for same-day shipping

In Stock

Regular price: $41.07
Sale price: $41.07
Regular price

Shipping calculated at checkout.

Looking for something slightly different? Check out these variations:

Holding Force: Up to 300 lbs (136 kg)
Current Draw: 12V / 300mA ; 24V / 150mA (±5%)
Green/Red LED Indication for EM Lock Status
This is a Fail Safe or Normally Close lock, meaning it will unlock without power.

Quantity:

Free US Shipping
To all 50 states

3 YEAR Warranty

30-Day Returns
No questions asked

Lifetime Phone Support
Mon–Fri 9am–6pm EST

ATTENTION:

Before purchasing, it is recommended that the customer checks with their local fire authority to see if there is any additional product they may need in order to comply with the local fire codes. We are not responsible for the improper installation of our product(s) or any type of fees that can be incurred by not complying with your local fire authority.
