This PRODUCT has a 3 YEAR warranty with full access to tech support in the USA!

Description

The Visionis EL104-FSESA is an eletric strike lock that is interchangeable between two settings. It can be fail safe normally closed or fail secure normally open. This strike provides 770lbs of reinforcement. This model can be used on wood, metal, and PVC doors. Whether it is for a simple or advanced access control system, this strike suits multiple security needs and is reliable. The strike is installed within your door frame and used to secure your door for your access purposes.

Electric strikes are great for doors,small enclosures or any area door you would like to give added security to at any time. As mentioned, this particular electric strike is interchangeable between fail safe and fail secure. Fail safe means that in the case of a power outage, the latch will disengage and the door will become unlocked. Fail secure means that in the case of a power outage, the latch will engage and the door will become locked.

(these products do not include a power supply)



Attention:

  • Comes with Standard USA Size for the electric strike (VIS-EL104-FSESA)
Characteristics

Model No. VIS-EL104-FSESA:

  • Lock Size: 124.6Lx32.3H (mm) - 4.90Lx1.27H (in.)
  • Holding Strength: 350kg (770 pounds)
  • Voltage: 12VDC
  • Current: 12VDC - 280mA // 24VDC - 140mA
  • Feature: Fail Safe and Fail Secure Adjustable
  • Suitable For: Wooden Door, Metal Door, PVC Door
  • Cycles Tested: 300.000
  • Operating Temperature: -15°C / +40°C (5°F / 104°F)
  • Product + Packaging Weight: 0.50kg (1.10 pounds)

Description

The Visionis EL104-FSESA is an eletric strike lock that is interchangeable between two settings. It can be fail safe normally closed or fail secure normally open. This strike provides 770lbs of reinforcement. This model can be used on wood, metal, and PVC doors. Whether it is for a simple or advanced access control system, this strike suits multiple security needs and is reliable. The strike is installed within your door frame and used to secure your door for your access purposes.

Electric strikes are great for doors,small enclosures or any area door you would like to give added security to at any time. As mentioned, this particular electric strike is interchangeable between fail safe and fail secure. Fail safe means that in the case of a power outage, the latch will disengage and the door will become unlocked. Fail secure means that in the case of a power outage, the latch will engage and the door will become locked.

(these products do not include a power supply)



Attention:

  • Comes with Standard USA Size for the electric strike (VIS-EL104-FSESA)
Characteristics
Packaging of this product

Model No. VIS-EL104-FSESA:

  • Lock Size: 124.6Lx32.3H (mm) - 4.90Lx1.27H (in.)
  • Holding Strength: 350kg (770 pounds)
  • Voltage: 12VDC
  • Current: 12VDC - 280mA // 24VDC - 140mA
  • Feature: Fail Safe and Fail Secure Adjustable
  • Suitable For: Wooden Door, Metal Door, PVC Door
  • Cycles Tested: 300.000
  • Operating Temperature: -15°C / +40°C (5°F / 104°F)
  • Product + Packaging Weight: 0.50kg (1.10 pounds)
  • What door types is this electric strike compatible with?

    It is designed for wood, metal, and PVC doors, making it a versatile option for both residential and commercial installations

  • Is this door strike weatherproof?

    No, this electric strike is not weatherproof. It is designed specifically for indoor use.

  • Does it have a built-in alarm?

    No, this electric door strike does not have a built-in audible alarm.

  • Can this be used for commercial purposes?

    Yes, this door strike model is ideal for commercial use, offering 770 lbs holding force, fail-secure functionality, perfect for securing interior doors in offices, retail, or restricted areas.

Download Datasheets and Manuals of this product

VIS-EL104-FSESA

Contact Us for Support

LET US HELP YOU WITH YOUR PURCHASE

Feel free to contact our dedicated support team if you have any questions or if you're ready to place an order.

I Need Help
Visionis by Visionis

5.0

2 reviews

Electric Door Strike with 770lbs (350kg) Holding Strength for Wood and Metal Doors. 12V Fail Safe Normally Closed and Fail Secure Normally Open Adjustable - VIS-EL104-FSESA Visionis

Translation missing: en.products.product.sku:VIS-EL104-FSESA

UPC Code: 723980159857 Weight: 2.0 lb
  • CE Certificate

  • This model can be used on wood, metal, and PVC doors.
  • Fail safe and fail secure adjustable
  • Holding Strength: 350kg (770 pounds)
  • Voltage: 12VDC

THIS PRODUCT DOES NOT INCLUDE A POWER SUPPLY
