VIS-3003 Waterproof Keypad and Card Reader Description

The Visionis VIS-3003 is a cutting-edge outdoor access control keypad, designed for maximum security and durability in any environment. With its IP68-rated waterproof and dust-tight construction, this device is perfect for outdoor or indoor use.

Supporting up to 1,000 users, it provides flexible access methods including card, code, or a combination of both, making it a reliable option for high-security applications. Its sleek metal anti-vandal design and durable backlit keypad ensure ease of use, even in low-light conditions.

As part of Visionis' standalone access keypads, the VIS-3003 offers unparalleled reliability for residential, commercial, and industrial properties.

VIS-3003 Features

• IP68 Waterproof & Dust-Tight Design: Ideal for outdoor use.
• Standalone Access Control Keypad: No software required for operation.
• Supports Multiple Access Methods: Card, code, or card + code for added flexibility.
• Durable Metal Construction: Anti-vandal and built to last.
• Wiegand 26 Integration: Seamless connectivity with existing systems.




VIS-MINI-CNTRL Mini Controller Description

This keypad comes with the VIS-MINI-CNTRL. This device is a mini single door control panel that can work with any Wiegand 26~37 bits output reader. It uses Atmel microcontroller to assure stable performance, and it is equipped with an infrared remote control for easy operation. The VIS-MINI-CNTRL supports 1,000 users.

VIS-MINI-CNTRL Features

• User Capacity: 1,000
• Multi access modes: Card, Card or PIN, Card with PIN and multi Cards/PINs
• Can connect with any reader with Wiegand 26~37 bits output
• Can connect with any keypad reader with 4bits, 8bits (ASCII), or 10bits virtual number output
• Support Master Card function
• Low temperature resistance (-40°C)



IMPORTANT:

• These products do not include a power supply
• Professional installation is recommended.
• For better security the VIS-MINI-CNTRL needs to be installed inside the facility in a restricted area. This device becomes the hub of this standalone application and all the credentials are being stored on the device while no information is stored on the reader itself. Additional recommendations for added security is to add the controller within an enclosure.
• If the keypad/card reader (entry device) is tampered with, the door will remain locked. The mini controller is the one controlling and securing your locking device.
• The VIS-MINI-CNTRL offers a more secure option to provide additional security to all type of standalone access control products.

---
